Daily Maintenance of Hydraulic Pumps
1. Scientific Management of Hydraulic Fluid
-
Oil Selection and Replacement Cycle
The viscosity, anti-wear properties, and oxidation resistance of hydraulic oil must strictly match the pump's design requirements (e.g., piston pumps require extremely high oil cleanliness). It is recommended to replace hydraulic oil according to the manufacturer's recommended cycle. Under harsh conditions such as high dust or high temperatures, the replacement interval should be shortened. -
Fluid Contamination Control
Statistics show that over 70% of hydraulic pump failures originate from fluid contamination. Regularly monitor particle content in the oil (per ISO 4406 standard), use high-precision filter elements (recommended β-value ≥ 200), and avoid introducing impurities during refueling or maintenance.
2. Regular Inspection of Key Components
-
Sealing System: Check for leaks in seals such as shaft seals and O-rings. Seal failure directly leads to fluid loss and air ingress.
-
Bearings and Drive Components: Listen for abnormal noises during pump operation. Regularly inspect bearing temperature (recommended not to exceed 80°C) and coupling alignment.
-
Suction Line: Ensure the suction inlet filter is unobstructed to prevent cavitation damage inside the pump.
3. Monitoring of Operating Parameters
Monitor the pump's outlet pressure, flow rate, and oil temperature in real-time using pressure gauges, flow meters, and temperature sensors. Abnormal fluctuations are often early indicators of potential failures. For example:
-
Increased Pressure Pulsation: May indicate internal wear or failure of the valve plate.
-
Abnormal Oil Temperature Rise: Requires checking the cooling system or investigating potential overload conditions.
Typical Fault Diagnosis and Response Measures
| Fault Phenomenon | Possible Causes | Diagnostic Methods | Solutions |
|---|---|---|---|
| Insufficient Output Flow | 1. Suction oil filter clogged 2. Internal pump wear (e.g., impeller or rotor wear) 3. Excessive or insufficient oil viscosity |
• Check suction oil filter pressure differential • Disassemble pump to measure key component clearance • Use viscometer to test oil viscosity |
• Clean or replace suction oil filter element • Repair or replace worn rotor, shaft, or distributor plate • Replace with oil of appropriate viscosity |
| Abnormal Noise or Vibration | 1. Cavitation (air leakage in suction line or air entrained in oil) 2. Bearing damage 3. Excessive misalignment of coupling 4. Loose internal pump components |
• Listen for cavitation sound (sharp "popping" noise, bearing failure may produce rumbling) • Infrared thermography to detect abnormally high temperature areas on bearings • Use laser alignment instrument to check coupling alignment |
• Check suction piping seal integrity and bleed air • Replace bearing and add lubricant • Realign coupling to precision ≤0.05mm • Tighten loose internal components |
| Pressure Cannot Be Built Up | 1. Relief valve stuck or incorrectly set 2. Variable displacement pump control valve jammed 3. Sealing failure causing internal leakage 4. Contaminated hydraulic oil blocking control lines |
• Segmental pressure testing method (separate pump from system) • Disassemble variable displacement mechanism to check movement flexibility • Internal leakage detection (compare theoretical flow with actual flow) |
• Clean or replace relief valve • Clean and polish control valve spool, apply anti-wear coating • Replace sealing components (e.g., piston seals) • Replace hydraulic oil and clean system |
| Abnormally High Oil Temperature | 1. System running under prolonged overload 2. Cooling efficiency reduced (water-cooled/air-cooled failure) 3. Oil oxidation or water contamination causing reduced viscosity |
• Monitor motor current to determine if load exceeds limit • Check coolant flow rate or fan speed • Oil acidity test (acid value > 1.5mgKOH/g indicates oxidation) |
• Optimize operating conditions to avoid overload • Clean cooling pipes or replace fan motor • Replace hydraulic oil and add antioxidant |
| External Leakage | 1. Shaft seal aging or wear 2. Loose bolts at pump housing joint 3. Cracks in housing (casting defects or overloading) |
• Visual inspection for leak points (shaft end, joint surfaces) • Use torque wrench to check bolt tightening force • Fluorescent penetrant inspection for micro-cracks in housing |
• Replace shaft seal (pay attention to installation direction) • Retighten bolts to standard torque values • Repair by welding or replace housing |
